Key Features
High Definition School Bus Video Surveillance Solution
1080p resolution easily catch a moving vehicle's plate number.
2Ch
One front camera facing the road and one rear cam facing the cabin
H265 coding/decoding technology
Twin 256 GB SD cards. Each card can record 256 hours of video.
Wi-Fi
Automated data file download via Wi-Fi. No need to remove disks.
4G Technology
Talk with other drivers using the live streaming feature on the MDVR
Technical Specifications
A cost-effective and high extendibility, this dashcam was developed specifically for vehicle monitoring and remote video surveillance.
A high-speed processor HI3521D and embedded Linux system is combined with the most advanced technology of H.265 coding/decoding, 3G/4G network, GPS/BD, and Wi-Fi.
With the ability to support 1080p and720p while producing high resolution video recording, the dashcam has a vehicle driving record and video remote uploading. The central software can do remote monitoring based on alarm linkage, vehicle dispatch management, and playback analysis based on central database.
The dashcam has a built-in ADAS and DSM module, which can recognize fatigued driving, left-handed/unusual hand positions, smoking, making phone calls, lane departures, and other troublesome behaviors. It can capture and report all information − all it takes is an update to your preferences in your settings. This device is competitive in anti-vibration, rich function, high reliability, concise appearance,and it's simple to deploy.
- Industrial-grade design with special vehicle port for reliable working on harsh environment.
- Wide voltage support over-load ,short circuit ,reverse connect protection.
- UPS power for continual work.
- Support 2 SD card 256G for record storage.
- 3/4G/5G wireless transmission module; Wi-Fi module, 2.4G/5.8G optional.
- GPS/BD/GLONASS global positioning.
- Powerful software platform including remote preview, playback, broadcast, talk and more.
- PTT group talk function.
- Support multiple serial port extension.
Video and Preview
Video Input, Output, Signal standard | 2-way 1080P input (built-in front and rear dual-view cameras) 1 built-in speaker (intercom, voice prompt) |
Audio and video Parameters of the code | optional H265, H264 encoding |
Storage Medium | Supporting two SD cards for storage, each one max support 256GB |
Communication Port | Supports 1 RS232. Can be attached sensor; Support 1 channel level input,1 channel output, can expand 1 channel analog output |
G-Sensor | Collision detection after parking; Support acceleration, rolloff, trigger alarm for collision condition |
Audio
Audio Input, Output | 4ch audio input, 1ch audio output. Independent intercom |
Recording
Storage Midium | Supporting one 2.5" SATA hard drive(max 2TB) and one SD card(max 256GB) |
Video | Recording at start up by default, supporting timed recording, recording triggered by alarm and event, as well as manual recording |
Alarm recording | 0-60 min |
Playback channel | Support local 1/4/6/8 channel playback |
Wireless Transmission
3/4G/5G wireless transmission module, EVDO/TD-SCDMA/WCDMA/TDD-LTE/FDD-LTE ect. |
Position
GPS/BD: Positioning, speed detection, time synchronization |
Power Supply and Power Consumption
Power Supply | ≤6V, ACC on; ≥7.5V, ACC off |
Input Voltage | DC:+8V ~ +36V. If voltage is lower than 8V or is higher than 36V for a long time. The device automatically shuts down and enters the protection mode. |
Output Voltage | [email protected]; [email protected] |
Power Consumption | Max 30W consumption, about 10W in standby mode |
Operating Environment
Temperature | preheating: -20C ~ +70C |
Humidity | 8% to 90% |
Design
Dimensions | 177(L) x 186.8(W) x 54(H) |
Weight | Net: 2.1 KG |
